40HP 10 Bar Small Rotary Screw Air Compressor 30kw Portable

  • 40HP 10 Bar Small Rotary Screw Air Compressor 30kw Portable
  • 40HP 10 Bar Small Rotary Screw Air Compressor 30kw Portable
  • 40HP 10 Bar Small Rotary Screw Air Compressor 30kw Portable
Place of Origin CHINA
Brand Name OEM
Certification CE
Model Number CHIC-40A
Minimum Order Quantity 1
Price USD 40-45
Packaging Details packing size(L×W×H)：1300mm×850mm×1210mm
Delivery Time 7days
Supply Ability 500Pcs/Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name 30kw 40hp CHIC-40A 10Bar Direct Driven Used Portable Screw Air Compressor Air Delivery 3.4m³/min
Electricity Three Phase 380/60 Or 440/60 (V//Hz) Pressure 10Bar
Noise Level 68±2dB Power 40HP/30KW
N.weigh 550KGS Color Blue
Highlight

40HP small rotary screw air compressor

,

30kw small rotary screw air compressor

,

40HP 30KW screw type air compressor
Leave a Message
Product Description

10 Bar Small Rotary Screw Air Compressor CHIC-40A 30kw Portable



Double control system electric control and air hole are combined which can be selected freely

Adopt advanced numerical control processing erquopment for production with high precision and reliability

Low -speed design strict correction of dynamic balance ,computer - optimized design make the operation more stable

cooler:Aluminum fin structure, heat exchange effect is good, reduce the temperature of the whole machine, ensure the air compressor working temperature tends to a stable range, unique structure, to meet all kinds of environment.

oil filter:High precision glass fiber oil filter, ensure the lubricating oil into the main engine crystallization, prolong the service life and maintenance cycle of the main engine.

oil-water separator:A specially designed oil and gas separation system ensures a lower pressure differential, thus reducing energy consumption. With advanced three-stage oil and gas separation, the oil content is controlled under 3ppm to ensure the high quality of compressed air.





Technical parameters



Model CHIC-40A
Power 40HP/30KW
FAD: (M3/MIN) 3.4
Pressure 10 bar
Cooling Air-cooling
Lubricant 15L
Noise level 68±2dB
Drive method Direct drive type
Discharge temperature Environment Temp+15℃-18℃
Electricity Three phase 220/60 or 440/60 (V//Hz)
Starting method Y-△ starter
Air outlet: Pipe diameter(inch)

G1″
delivery 15-20 days
Oil content of air <2ppm
Dimension 860MM*1115MM*1340MM
Net weight 490KGS



Packaging & Shipping



Packaging Details
Standard export carton or plywood case 1pcs/box
Port
Shanghai/Ningbo



40HP 10 Bar Small Rotary Screw Air Compressor 30kw Portable 0



40HP 10 Bar Small Rotary Screw Air Compressor 30kw Portable 1

Our services



1.We promise to reply your inquiry relational our product within 24hours.

2.OEM&ODM service for your unique idea with absolutely convenient.

3.Experienced foreign trader with professional product knowledge.

4.Value on business credite , promise to protect your sales data, design,patent information.

5. Sample & OEM service is available

6. After-sales service. any question will be settled within 3 days



FAQ



Q1. Are you a factory?
A. Yes, We are professional air compressor factory with more than 10 years experience.

Q2. How can i get a quotation?
A. Leave us message with your purchase requemets and we will reply you within one hour on working time. And you may contact us directly by Trade Manager

Q3. How many design do you have? How can i get your catalog?
A. We have hundreds of advanced design for your choice , And we have new design every year. Just tell us what kind of product you need and we will provide you plenty of choice,

Q4. How about your price?
A. Send me details about what you need, you will get the best price in China. The price is competitive over the world.

Q5. What's the delivery time and what's the package?
A. Normally the delivery time is about 25-35 days, Al our products are packed with sea worthy package.
