2400mm 1.5kw Robot Palletizer Machine

  • 2400mm 1.5kw Robot Palletizer Machine
  • 2400mm 1.5kw Robot Palletizer Machine
Place of Origin China
Brand Name CHIC
Certification CE ISO
Minimum Order Quantity 1 piece
Packaging Details Packing inside is plastic films and outside is fumigation wooden case.Our wooden case is very strong,it can bear long time shipping on the sea.And machine with preservative film,it can stop the salt sea water enter into the machine and make the machine cor
Delivery Time 25 working days
Payment Terms L/C, T/T, Western Union
Supply Ability 20 pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Fully Automatic Pallet Film Wrapping & Strapping Pallets Robot Palletizer Machine Packing Type Cartons, CANS, Bottles, Barrel, Bags, Case, Pallet
Dimension L 2650 X W 2000 X H 2900 Mm Weight 900 Kg
Speed 30-50 Pallets/hr Max. Loading 2000kg
Highlight

2400mm Robot Palletizer Machine

,

1.5kw Robot Palletizer Machine

,

1.5kw pallet wrapping machine
Leave a Message
Product Description

Product Application

T1800FZ-PL Automatic Online turntable pallet stretch wrapping machine are used to wrap stretch film around a loaded pallet. Film provides extra support while the products are being transported & storage to protect them from tip, spill from being damaged. Additionally, wrapper loads can easily be separated and identified.



Features

• Open door film carriage

• Limit built-in
• 1800mm wrapping height
• 2000kgs loading
• Spring break stretch
• Home position: the turntable always stops at the same position
• Speed control on turntable
• Choose between 1 & 9 top and bottom wraps with re-enforce wrap
• Up & down or up only wrap cycle
• Semi auto and manual wrap options
• Adjustable pallet height photo sensor
• Secure Top Sheet Function
• Lockable control panel
• Adjustable tension with quick release
• Soft start and stop
• Machine can be paused during cycle
• Magnetic brake holds turntable still during loading/unloading
• Audible warning when running a cycle



Specifications:

Model T1800FZ-PL
Wrapping size (800-1100)*(800-1200)mm
Wrapping height 800-1800/2400mm
Packing efficiency 30-50pallets/hour
Turntable size 1800mm
Turntable loading 2000kg
Turntable speed 0-12rpm
Voltage 220V/50HZ
Average power consumption 1.5kw
Machine size L2820*W1800*H3200mm
Weight 1000kg

Machine details:

2400mm 1.5kw Robot Palletizer Machine 0

Max Pre-stretch 350%
Adjustable tension with quick release

Installation and adjustment



2400mm 1.5kw Robot Palletizer Machine 1

Independent PLC Inverter Control
Frequency conversion motor has less abrasion and stable packaging
2400mm 1.5kw Robot Palletizer Machine 2




After the equipments are arrived at the customer’s site, the customers is responsible for unpacking and arranging the equipment according to the placement drawing; and do under our install-adjust technicians’ guidance.
According to requirement of water, electricity, air and steam consumption and the demands of quality level and pipeline, the User should connect the wire, cable and pipe of water, air and steam to the special position ordered in the installation area of production line ahead of time. Other relevant matching equipment and project should be finished before we adjust our equipment.
We’ll bring a suit of portable installation and adjustment tools ourselves during the period of installing and adjusting, the other instruments we need should be furnished by the customer for free including oxygen, acetylene angry, argon, etc. needed in the installation and adjustment site.
The customer should dispatch the capable person to accept training in the installing site.



Quality assurance


We guarantee the goods offered are brand-new, unused, with latest design and suitable material made, and we guarantee the specification of the equipments is consonance with the contract.
We are responsible for the fault and damage of the production line caused by our design, technology, manufacture, installation, adjustment and material defect etc that all belong to our responsibility.


Maintenance


Offer 12 months maintenance period to the problem that caused by our design, manufacture and the material quality, and offer the relevant parts and effective service for free for above reason. We will offer a widely and favorable technical support, after service all the time after guarantee period.
